用於光學和射頻的超材料和超表面：市場、技術、趨勢（2023-2029）：具有標準材料無法實現的特殊特性的超材料和超表面

超材料源自希臘文 "meta-" （意為超越），是一種智慧材料，具有天然材料所沒有的光子、聲學、機械和 RF（射頻）特性。這就是材料。

超材料是透過組合金屬和聚合物等標準材料並對其進行圖案化而創建的。 這些材料通常以重複圖案和小於波長的尺度排列。

超材料不僅源自於底層材料的特性，也源自新設計的結構。 它精確的形狀、幾何形狀、尺寸、方向和位置賦予它智慧特性，使其能夠操縱電磁波。

透過阻擋、吸收、放大或彎曲波，它們可以實現傳統材料無法實現或無法實現的優勢。

它確實是未來的材料。

2022 年 6 月，義法半導體宣布推出首款使用超表面的消費模組。

STMicro VL53L8 感測器是一款新型 3D dTOF（直接飛行時間）感測模組，採用與 Metalenz 合作開發的超表面。

超表面現已上市，將這種革命性的光學技術帶入真正的消費性設備。

這項世界首創的超表面技術是與Metalenz 合作開發的，可以讓光學系統收集更多的光，在單層中提供多種功能，並在智慧型手機和其他設備中實現新的使用形式，可以實現檢測功能。

本報告分析了用於光學和射頻應用的超材料和超表面的世界市場，提供了該技術的概述、主要應用領域、當前技術發展和引進狀況、未來產品商業化的前景，並提供了有關小型和無線射頻應用的資訊。我們收集並提供公司和大型企業的舉措狀況以及未來機會和挑戰等資訊。

本報告中列出的製造商

Anywaves、Carillon Technologies、Echodyne、Evolv Technology、Gapwaves AB、Greenerwave、Huawei Technologies、Kuang-Chi Group、Kymeta Corporation、Lumotive、Metalenz、MetaPower、Metawave Corporation、NIL Technology (NILT)、Pivotal Commware、Acree Technologies Incorporated、Antrum Ltd、appliedEM innovations、BlueHalo、Fractal Antenna Systems、Isotropic Systems、JEM Engineering、LongWave Photonics、Meta Material Inc、Metaboards、Metacept、Metamagnetics Inc.、Moxtek、Multiwave Technologies AG、Nano-Meta Technologies、Nanohmics、Notch Inc.、Phoebus Optoelectronics、Physical Sciences Inc.、Plasmonics Inc.、Radi-Cool、Sensormetrix、SI2 Technologies、TeraView、Tesla Dynamic Coils BV、Tunoptix、Ultimetas、Vadient Optics、Wave UP

+一家從事超材料和超表面研究的公司。

目錄

第 1 章簡介

第 2 章從 "隱形斗篷" 的概念到首次實際使用

• 用於光學和射頻的超材料 - 這意味著什麼？
• 豐富的想法和研究
• 從國防到射頻/光學

第 3 章中小企業市場開拓

• 價值鏈
• 市場數據
• 資金和主要合作夥伴關係
• 資助項目
• 專利
• 預測

第 4 章新產品

• 光學
• RF（射頻）
• 其他領域（聲學、機械）
• 作業

第 5 章影響未來利用領域趨勢的主要公司

• 光學市場的潛在顛覆
  • 適用於智慧型手機的超透鏡
  • AR/VR 設備的元組件
  • 用於光學計算的超表面
  • 用來顯示裝置的超表面
• 射頻市場的潛在顛覆
  • 適用於 5G/6G 系統的RIS (Reconfigurable Intelligent Surface)

第 6 章結論

第 7 章附錄

第 8 章關於 TEMATYS

Metamaterials from the Greek word "meta-" (meaning to go beyond), are smart materials engineered to have photonic, acoustic, mechanical or RF properties that are not found in naturally occurring materials.

They are made by combining and patterning standard materials such as metals or polymers. The materials are usually arranged in repeating patterns, at scales that are smaller than the wavelength.

Metamaterials derive their features not from the properties of the base materials, but from their newly designed structures. Their precise shape, geometry, size, orientation and arrangement gives them their smart properties capable to manipulate electromagnetic waves.

By blocking, absorbing, enhancing, bending waves, they achieve benefits that go beyond what is possible with conventional materials or are unachievable in other ways.

They are in essence the materials of the future.

IN JUNE 2022, STMICROELECTRONICS RELEASED THE FIRST CONSUMER MODULE USING A METASURFACE.

STMicro VL53L8 sensor is a new 3D direct Time-of-Flight (dToF) sensing module using metasurfaces developed through the partnership with Metalenz.

Metasurfaces are now on the market marking the introduction of this revolutionary optical technology in real-world consumer devices.

Developed in partnership with Metalenz, this first metasurface technology enables optical systems to collect more light, provide multiple functions in a single layer, and deliver new forms of sensing in smartphones and other devices, all in its compact package.

MANUFACTURERS MENTIONED IN THE REPORT:

Anywaves, Carillon Technologies, Echodyne, Evolv Technology, Gapwaves AB, Greenerwave, Huawei Technologies, Kuang-Chi Group, Kymeta Corporation, Lumotive, Metalenz, MetaPower, Metawave Corporation, NIL Technology (NILT), Pivotal Commware, Acree Technologies Incorporated, Antrum Ltd, appliedEM innovations, BlueHalo, Fractal Antenna Systems, Isotropic Systems, JEM Engineering, LongWave Photonics, Meta Material Inc., Metaboards, Metacept, Metamagnetics Inc., Moxtek, Multiwave Technologies AG, Nano-Meta Technologies, Nanohmics, Notch Inc., Phoebus Optoelectronics, Physical Sciences Inc., Plasmonics Inc., Radi-Cool, Sensormetrix, SI2 Technologies, TeraView, Tesla Dynamic Coils BV, Tunoptix, Ultimetas, Vadient Optics, Wave UP

+ COMPANIES CONDUCTING RESEARCH ON METAMATERIALS AND METASURFACES.
